Exterior lamps circuit, 5 door for Kia Rio I facelift (2002-2005)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMBINATION SWITCH DRL UNIT (BEHIND LEFT END OF DASH) ETWIS FLASHER UNIT (BEHIND LEFT END OF DASH) FUSE BOX (AT LOWER LEFT SIDE OF DASH) GRN WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD FUSE HAZARD RELAY HAZARD SWITCH HEAD HIGH MOUNT STOP LIGHT LEFT REAR COMBIN- ATION LAMP HOT AT ALL TIMES HOT IN ON INSTRUMENT CLUSTER JC-04 LEFT FRONT COMBIN- ATION LAMP LEFT LICENSE LIGHT LEFT TAIL FUSE RIGHT TAIL FUSE LEFT TURN INDICATOR LEFT TURN RIGHT TURN LT GRN/YEL WIRE MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT) OFF RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT COMBIN- ATION LAMP RIGHT LICENSE LIGHT RIGHT REAR COMBIN- ATION LAMP RIGHT TURN INDICATOR SC-08 SHORT CONNECTOR JC-04 SHORT CONNECTOR JC-08 SHORT CONNECTOR JC-12 SHORT CONNECTOR SC-02 SHORT CONNECTOR SC-03 STOP FUSE STOP LAMP STOPLIGHT SWITCH (ABOVE BRAKE PEDAL) TAIL LAMP TNS TNS FUSE TNS RELAY TURN LAMP TURN LAMP FUSE TURN LAMP STOP LAMP TAIL LAMP W/ DRL W/O DRL WHT WIRE WHT/BLU WIRE YEL WIRE
