Back-up lamps circuit for Kia Rio I facelift (2002-2005)
Back-up lamps circuit
A/T
BACK UP LAMP
BACK-UP LAMP SWITCH (ON TRANSAXLE REAR COVER)
BLK WIRE
BLU/BLK WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LEFT REAR COMBINATION LAMP
M/T
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPARTMENT)
METER FUSE
POWER DISTRIBUTION SYSTEM
RIGHT REAR COMBINATION LAMP
SHORT CONNECTOR JC-12
SHORT CONNECTOR SC-03
TRANSMISSION CONTROL MODULE (BEHIND LEFT KICK PANEL)
TRANSMISSION RANGE SWITCH (ON TOP LEFT OF TRANSAXLE)
YEL WIRE
