Kia Rio I facelift (2002-2005) short connector sc-09 Wiring diagram
This page shows the only wiring diagram for the component.short connector sc-09, which is found in the car Kia Rio I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram short connector sc-09 (1 of 1)
ABS FUSE
ABS UNIT
AIR BAG FUSE
AIR BAG UNIT
AIR CON MAIN SWITCH
AUDIO
AUTO CLOCK
B-01
BACK-UP LAMP SWITCH ABS, EBO RELAY SPEED SENSOR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CIGAR LIGHTER ILLUMI- NATION
COMBINATION SWITCH (PASS SWITCH)
DIAGNOSIS CONNECTOR
DRL RELAY
ENGINE CONTROL MODULE
FOGLAMP SWITCH
FROM HORN FUSE (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM ILLUM FUSE (DIAGRAM 1 OF 3)
FUSE
FUSE BOX (AT LOWER LEFT SIDE OF DASH)
GRN WIRE
HAZARD SWITCH
HEAD FUSE
HEADLIGHT RELAY
IGNITION COIL 1, IGNITION COIL 2,
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER ASHTRAY ILLUMI- NATION
LEFT REAR POWER WINDOW SWITCH
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT)
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT) IG COIL FUSE
METER FUSE
MODE SWITCH RIGHT REAR POWER WINDOW SWITCH
PANEL LIGHT SWITCH
POWER WINDOW MAIN SWITCH
RED WIRE
RIGHT POWER WINDOW SWITCH
SEAT WARMER SWITCH REAR WIPER, WASHER SWITCH
SHIFT LOCK UNIT
SHORT CONNECTOR SC-03
SHORT CONNECTOR SC-05
SHORT CONNECTOR SC-09
STARTER RELAY
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TRANSMISSION CONTROL MODULE CONDENSER
TRANSMISSION RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> SHORT CONNECTOR SC-09
