Kia Rio I facelift (2002-2005) right rear power window switch Wiring diagram
This page shows the only wiring diagram for the component.right rear power window switch, which is found in the car Kia Rio I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear power window switch (1 of 1)
AIR CON MAIN SWITCH
ASHTRAY ILLUMINATION
AUDIO
AUTO CLOCK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
CIGAR LIGHTER ILLUMINATION
FOG LAMP SWITCH
FUSE BOX (AT LOWER LEFT SIDE OF DASH)
HAZARD SWITCH
HOT W/ TNS RELAY ENERGIZED
ILLUM
ILLUM FUSE
INSTRUMENT CLUSTER
J/C 10
JC-04
JC-08
LEFT REAR POWER WINDOW SWITCH
MODE SWITCH
OSC
PANEL LIGHT SWITCH
POWER WINDOW MAIN SWITCH
REAR WIPER/ WASHER SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW SWITCH
SC-09
SEAT WARMER SWITCH
W/ REAR PWR WINDOWS
W/O REAR PWR WINDOWS
WHT WIRE
Go to component -> Instrument illumination circuit -> RIGHT REAR POWER WINDOW SWITCH
