Kia Rio I facelift (2002-2005) right power window switch Wiring diagrams
This page contains all the electrical diagrams for the component. right power window switch, in which he is found in the car Kia Rio I facelift (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right power window switch (1 of 3)
AIR CON MAIN SWITCH
ASHTRAY ILLUMINATION
AUDIO
AUTO CLOCK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
CIGAR LIGHTER ILLUMINATION
FOG LAMP SWITCH
FUSE BOX (AT LOWER LEFT SIDE OF DASH)
HAZARD SWITCH
HOT W/ TNS RELAY ENERGIZED
ILLUM
ILLUM FUSE
INSTRUMENT CLUSTER
J/C 10
JC-04
JC-08
LEFT REAR POWER WINDOW SWITCH
MODE SWITCH
OSC
PANEL LIGHT SWITCH
POWER WINDOW MAIN SWITCH
REAR WIPER/ WASHER SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW SWITCH
SC-09
SEAT WARMER SWITCH
W/ REAR PWR WINDOWS
W/O REAR PWR WINDOWS
WHT WIRE
Go to component -> Instrument illumination circuit -> RIGHT POWER WINDOW SWITCH
Wiring diagram right power window switch (2 of 3)
ABS FUSE
ABS UNIT
AIR BAG FUSE
AIR BAG UNIT
AIR CON MAIN SWITCH
AUDIO
AUTO CLOCK
B-01
BACK-UP LAMP SWITCH ABS, EBO RELAY SPEED SENSOR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CIGAR LIGHTER ILLUMI- NATION
COMBINATION SWITCH (PASS SWITCH)
DIAGNOSIS CONNECTOR
DRL RELAY
ENGINE CONTROL MODULE
FOGLAMP SWITCH
FROM HORN FUSE (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM ILLUM FUSE (DIAGRAM 1 OF 3)
FUSE
FUSE BOX (AT LOWER LEFT SIDE OF DASH)
GRN WIRE
HAZARD SWITCH
HEAD FUSE
HEADLIGHT RELAY
IGNITION COIL 1, IGNITION COIL 2,
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER ASHTRAY ILLUMI- NATION
LEFT REAR POWER WINDOW SWITCH
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT)
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT) IG COIL FUSE
METER FUSE
MODE SWITCH RIGHT REAR POWER WINDOW SWITCH
PANEL LIGHT SWITCH
POWER WINDOW MAIN SWITCH
RED WIRE
RIGHT POWER WINDOW SWITCH
SEAT WARMER SWITCH REAR WIPER, WASHER SWITCH
SHIFT LOCK UNIT
SHORT CONNECTOR SC-03
SHORT CONNECTOR SC-05
SHORT CONNECTOR SC-09
STARTER RELAY
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TRANSMISSION CONTROL MODULE CONDENSER
TRANSMISSION RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> RIGHT POWER WINDOW SWITCH
Wiring diagram right power window switch (3 of 3)
BLK WIRE
BLU WIRE
DOWN
ETWIS
GRN WIRE
HOT AT ALL TIMES
JC-04
LEFT POWER WINDOW MOTOR
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPARTMENT)
P/WIN FUSE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY (IN MAIN FUSE BOX)
RED WIRE
RED/WHT WIRE
RIGHT POWER WINDOW MOTOR
RIGHT POWER WINDOW SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, without rear power windows -> RIGHT POWER WINDOW SWITCH
