Kia Rio I facelift (2002-2005) left fog lamp right fog lamp Wiring diagram
This page shows the only wiring diagram for the component.left fog lamp right fog lamp, which is found in the car Kia Rio I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left fog lamp right fog lamp (1 of 1)
B-04 ENGINE CONTROL MODULE (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
COMBINATION SWITCH
ETWIS
FOGLAMP RELAY
FOGLAMP SWITCH
GRN WIRE
HEAD FUSE
HEAD HIGH FUSE
HEAD LOW FUSE
HEADLIGHT RELAY
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON
ILLUM
INSTRUMENT CLUSTER
JC-04
JC-08
LEFT FOG LAMP RIGHT FOG LAMP
LEFT HEADLIGHT
MAIN FUSE BOX (AT LEFT REAR OF ENGINE COMPT)
ON IND.
PASS
RED WIRE
RELAY/ FUSE
RIGHT HEADLIGHT
SC-10
TNS FUSE
TNS OFF HEAD
TNS RELAY
WHT WIRE
X-03
YEL WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, without drl -> LEFT FOG LAMP RIGHT FOG LAMP
