Kia Rio I facelift (2002-2005) knock sen shield Wiring diagram
This page shows the only wiring diagram for the component.knock sen shield, which is found in the car Kia Rio I facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram knock sen shield (1 of 1)
1 2 3 4 5 6 7 8 9 B-01 IGN
8 9 B-05
A/C ON RELAY
B-09
B-10
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
CONDENSER (LEFT REAR OF ENG, NEAR IGNITION COILS)
COOLING FAN RELAY
DIAG K-LINE GND GND GND BATT IGN IGN
ECU FUSE
EMS FUSE
ENG RPM SIG
ENGINE CONTROL MODULE (BELOW LEFT SIDE OF DASH)
EVAP PURGE SOL ISC CTRL (OPEN) ISC CTRL (CLOSE)
FUEL INJECTORS
FUEL PUMP FUSE
FUEL PUMP RELAY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG-COIL FUSE
IGN COIL CTRL 1
IGN COIL CTRL 2
IGNITION COIL 1
IGNITION COIL 2
INJECT FUSE
KNOCK SEN GND
KNOCK SEN IN INJ 2 CTRL INJ 4 CTRL INJ 1 CTRL INJ 3 CTRL
KNOCK SEN SHIELD
MAF SEN GND
MAF SEN IN
MAIN RELAY
NCA WIRE
ORG/ WIRE
PURGE SOLENOID (RIGHT FRONT OF ENG)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SHORT CONNECTOR SC-03 (BEHIND DASH, RIGHT OF STEERING COLUMN)
SHORT CONNECTOR SC-05 (BELOW LEFT SIDE OF DASH)
SPARK PLUGS
TORQUE SIG TPS SIG
TPS VOLTAGE
WHT WIRE
X-03
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.6l (1 of 3) -> KNOCK SEN SHIELD
