Kia Rio X I (2020-2024) vehicle spd Wiring diagram
This page shows the only wiring diagram for the component.vehicle spd, which is found in the car Kia Rio X I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle spd (1 of 1)
4 DOOR
5 DOOR
AUDIO UNIT
AUX, USB JACK
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CAMERA B+
CAMERA GND
CAMERA VIDEO
CAMERA VIDEO (OUT)
CAMERA VIDEO GND
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
FL (-)
FR (-)
GRN WIRE
GRY WIRE
ILL
LEFT REAR DOOR SPEAKER
MTS KEY IN
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
REAR VIEW CAMERA
REAR VIEW CAMERA, TAILGATE HANDLE SWITCH
RED WIRE
REMOTE CTRL SW GND
REMOTE CTRL SW SIG
RIGHT REAR DOOR SPEAKER
RL (+)
RR (-)
SHIELD GND
TAILGATE HANDLE SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
USB D (-) USB VCC
USB D-
USB GND
USB VCC
VEHICLE SPD
VIDEO+
WHT WIRE
YEL WIRE
Go to component -> Radio circuit (3 of 3) -> VEHICLE SPD
