Kia Rio X I (2020-2024) int off off lo Wiring diagram
This page shows the only wiring diagram for the component.int off off lo, which is found in the car Kia Rio X I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int off off lo (1 of 1)
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
FRONT WASHER SWITCH
FRONT WIPER MOTOR
FRONT WIPER SWITCH
GND SIG 1
GRN WIRE
GRY WIRE
HI MIST MIST
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BLOCK
I/P-A
I/P-C
I/P-D
INSTRUMENT CLUSTER
INT LO
INT OFF OFF LO
LO OFF
LOW WASHER LEVEL
MICOM
MIST
MULTI- FUNCTION SWITCH
OFF
ORG/ WIRE
PARKING SWITCH
PCB
PCM
PNK WIRE
REAR WIPER/ WASHER CIRCUIT
RED WIRE
WASHER LEVEL SENSOR
WASHER LOW IND
WASHER MOTOR
WHT WIRE
WIPER FRT FUSE
WIPER FUSE
WIPER SIG
YEL WIRE
Go to component -> Front wiper/washer circuit, w/o bcm -> INT OFF OFF LO
