Kia Rio X I (2020-2024) battery sens Wiring diagrams
This page contains all the electrical diagrams for the component. battery sens, in which he is found in the car Kia Rio X I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram battery sens (1 of 2)
ALT FUSE
ALT OUT
ALTERNATOR
ALTERNATOR (L)
AMS FUSE
AUDIO
BATTERY
BATTERY JUNCTION BLOCK
BATTERY SENS
BATTERY SENSOR
BLK WIRE
BLU WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
CHARGE IND
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
GND SIG 1
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN ON OR START
I/P JUNCTION BLOCK
I/P-C
INSTRUMENT CLUSTER
LIN LINE
MICOM
MULTI FUSE
PCM
RED WIRE
SENS
STARTING CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> BATTERY SENS
Wiring diagram battery sens (2 of 2)
A/C RELAY CTRL
AIR CONDITIONING SYSTEM
ALT LIN
BATTERY SENS
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE SW IN
BRAKE TEST SW
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C/FAN RLY CTRL HI
CCV CTRL
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CVVT EXHAUST CTRL
CVVT INTAKE CTRL
DEFOGGER SYSTEM
DEFROST HIGH
EGR MOTOR (-)
ENG RPM
FP RELAY CTRL
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IMMO DATA LINE
INJ 1 CTRL
INJ 2 CTRL
INJ 4 CTRL
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
MAIN RELAY CTRL
MEMORY PWR
ORG/ WIRE
ORG/BLK WIRE
PCM
PCSV CTRL
PNK WIRE
PNK/BLK WIRE
RED WIRE
START RLY CTRL HI
START RLY CTRL LO
STARTING/CHARGING SYSTEM
TMM MOTOR
VIS CTRL
W/ IMMOBILIZER
W/O IMMOBILIZER
WHT WIRE
WIPER SW IN
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l (5 of 7) -> BATTERY SENS
