Tire pressure monitoring circuit for Kia Rio X-Line I (2017-2020)

BLK WIRE BLU WIRE C-CAN HIGH C-CAN LOW C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM GND SIG 1 HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BLOCK I/P-C IGN 1 INSTRUMENT CLUSTER LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MEMORY PWR MICOM MODULE 7 FUSE PNK ON/START I/P WIRE PNK WIRE POWER CONNECTOR RED WIRE RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR ROOM LAMP FUSE TPMS IND TPMS UNIT WHT WIRE
