Kia Rio X-Line I (2017-2020) high wiper relay control Wiring diagram
This page shows the only wiring diagram for the component.high wiper relay control, which is found in the car Kia Rio X-Line I (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high wiper relay control (1 of 1)
A/T
B-CAN HIGH
B-CAN LOW
BCM
BLADE POS SW IN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
FRONT WASHER SW
FRONT WASHER SWITCH
FRONT WIPER SW
GRN WIRE
GROUND
GRY WIRE
HIGH SWITCH
HIGH WIPER RELAY CONTROL
INT (VOLUME)
INT SWITCH
LOW SWITCH
LOW WIPER RELAY CONTROL
M/T
MIST SWITCH
MULTI- FUNCTION SWITCH
ORG/ WIRE
PCM (A/T) ECM (M/T)
PNK WIRE
REAR WIPER/ WASHER CIRCUIT
RED WIRE
VOL 1 VOL 2 (FAST)
VOL 3
VOL 4
VOL 5 (SLOW)
WASHER MOTOR
WHT WIRE
WIPER FUSE
WIPER HIGH RELAY
WIPER LOW
WIPER LOW RELAY
WIPER LOW SWITCH
WIPER SIG
YEL WIRE
Go to component -> Front wiper/washer circuit, w/ bcm (1 of 2) -> HIGH WIPER RELAY CONTROL
