Kia Rio X-Line I (2017-2020) antenna coil ignition key illumination, door warning switch Wiring diagram
This page shows the only wiring diagram for the component.antenna coil ignition key illumination, door warning switch, which is found in the car Kia Rio X-Line I (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram antenna coil ignition key illumination, door warning switch (1 of 1)
ANTENNA COIL IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
ANTI-THEFT SYSTEM
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DOOR OPEN IND
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SW
EXT BUZZER
EXTERNAL BUZZER
GND (BCM)
GND SIG 1
GRN WIRE
GRY WIRE
HEAD
HEADLAMP
IGN 1
INSTRUMENT CLUSTER
LIGHT SW OUT
LIGHT SWITCH
MICOM
MULTI-FUNCTION SWITCH (W/ BCM)
MULTI-FUNCTION SWITCH (W/O BCM)
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
SEAT BELT
SEAT BELT IND
SMART KEY CONTROL MODULE
SYSTEM
TAIL
TRANSPONDER
W/ BCM
W/O BCM
W/O SMART KEY
WHT WIRE
Go to component -> Chime circuit (2 of 2) -> ANTENNA COIL IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
