Kia Optima IV facelift (2018-2020) turn sig lp sw out Wiring diagram
This page shows the only wiring diagram for the component.turn sig lp sw out, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn sig lp sw out (1 of 1)
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW PNK STOP LP SW WIRE
BACKUP LAMP
BACKUP LAMPS CIRCUIT
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
GND (BCM)
GRY WIRE
GRY/BLK WIRE
HAZARD SW
HEADLAMP
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-E
IPS 1 CTRL
IPS 2 CTRL
IPS 3 CTRL
IPS 7 CTRL
IPS 8 CTRL
IPS CONTROL MODULE
LEFT TURN
LIGHT SW OUT
LIGHT SW SIG
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED/BLK WIRE
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT TURN
SMART JUNCTION BLOCK
STOP LAMP
TAIL
TAIL LAMP
TURN LAMP
TURN LP SIG
TURN SIG LP SW OUT
WHT WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Exterior lamps circuit, except hybrid (1 of 3) -> TURN SIG LP SW OUT
