Kia Optima IV facelift (2018-2020) scc cruise on/off wiring diagram
This page shows the only wiring diagram for the component.scc cruise on/off, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
scc cruise on/off wiring diagram (1 of 1)
APS 1 GROUND
APS 1 POWER
APS 1 SIGNAL
APS 2 GROUND
APS 2 POWER
APS 2 SIGNAL
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SW
BRAKE SIG
BRAKE TEST SW
BRN WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
DOWN
E/R-D
ECU 2 FUSE
ETC DC MOTOR -
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HPCU
HYBRID POWER CONTROL UNIT
ILL
LEFT FRONT STRUT TOWER)
MEMORY POWER
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PCM
PNK WIRE
RED WIRE
RES+
RIGHT TRIP/CRUISE REMOTE CONTROL SWITCH
SCC CRUISE ON/OFF
SET-
STEERING WHEEL)
STOP LAMP SW
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS POWER
TRIP
VEHICLE SPEED
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit, hybrid (1 of 3) -> SCC CRUISE ON/OFF
