Kia Optima IV facelift (2018-2020) pdw lin pas lin Wiring diagram
This page shows the only wiring diagram for the component.pdw lin pas lin, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pdw lin pas lin (1 of 1)
AMP
B-CAN HIGH
B-CAN LOW
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
CLUSTER FUSE
CLUSTER SPEAKER
COMPUTER DATA LINES SYSTEM
CONSOLE SWITCH
DAC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
I/P-E
ILL
INPUT
INSTRUMENT CLUSTER
LEAK CURRENT AUTO CUT DEVICE
LEFT REAR PARKING ASSIST SENSOR
LEFT REAR PARKING ASSIST SENSOR (CENTER)
MEMORY 1 FUSE
MICOM
MODULE 3 FUSE
NCA WIRE
ON/START
ON/START INPUT
ORG/ WIRE
PAS IND
PAS MODE
PAS SWITCH
PDW LIN PAS LIN
RED WIRE
REG
RIGHT REAR PARKING ASSIST SENSOR
RIGHT REAR PARKING ASSIST SENSOR (CENTER)
RPAS POWER RPDW POWER
SIG GND
SMART JUNCTION BLOCK
SPEAKER OUT -
TRANSCEIVER/
W/ EPB W/O EPB PLUG-IN HYBRID EXCEPT PLUG-IN HYBRID EXCEPT HYBRID HYBRID
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> PDW LIN PAS LIN
