Kia Optima IV facelift (2018-2020) n position sw code pnk d position sw code pnk on/start input Wiring diagram
This page shows the only wiring diagram for the component.n position sw code pnk d position sw code pnk on/start input, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram n position sw code pnk d position sw code pnk on/start input (1 of 1)
2.0L TURBO 2.4L A/T DCT
B/UP LAMP FUSE
BACKUP
BACKUP LAMP
BLK WIRE
BLU WIRE
BRN WIRE
E/R-D
E/R-F
ELECTROCHROMIC MIRROR
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
N POSITION SW CODE PNK D POSITION SW CODE PNK ON/START INPUT WIRE
NCA WIRE
ON/START INPUT
P POSITION SW CODE
PCB BLOCK
PCM
PNK WIRE
PNK/BLK WIRE
R POSITION SW CODE
RED WIRE
REVERSE
RIGHT REAR COMBINATION LAMP (IN)
SIG
SIG (1)
SIG (2)
SIG 3
SIG 4
TCM
TCU 2 FUSE
TRANSAXLE RANGE SWITCH
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
WHT WIRE
Go to component -> Backup lamps circuit, except hybrid -> N POSITION SW CODE PNK D POSITION SW CODE PNK ON/START INPUT WIRE
