Kia Optima IV facelift (2018-2020) fog lamp sw input Wiring diagrams
This page contains all the electrical diagrams for the component. fog lamp sw input, in which he is found in the car Kia Optima IV facelift (2018-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fog lamp sw input (1 of 2)
AUTO HIGH BEAM IND
AUTO LIGHT SENS
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
COMPUTER DATA LINES SYSTEM
DRL IND
E/R JUNCTION BLOCK
FOG LAMP SW INPUT
FRONT FOG IND
GRY WIRE
HEADLAMP
HIGH BEAM IND
HIGH SW INPUT
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LIGHT SW SIG
LOW BEAM IND
MICOM
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
NCA WIRE
ORG/ WIRE
PARKING IND
PNK WIRE
POWER
RED WIRE
REG
RIGHT HEADLAMP
S GND
SIG
TAIL ON IND
TRANSCEIVER/
W/O JBL AMP W/ JBL AMP
WHT WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Autolamps circuit, except hybrid (2 of 2) -> FOG LAMP SW INPUT
Wiring diagram fog lamp sw input (2 of 2)
AUTO HIGH BEAM IND
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DRL IND
E/R JUNCTION BLOCK
FOG LAMP SW INPUT
FRONT FOG IND
GRY WIRE
HEADLAMP
HIGH BEAM IND
HIGH LOW
HIGH SW INPUT
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
INSTRUMENT CLUSTER
LEFT HEADLAMP
LIGHT SW SIG
LOW BEAM IND
MICOM
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
NCA WIRE
ORG/ WIRE
PARKING IND
PNK WIRE
RED WIRE
REG
RIGHT HEADLAMP
S GND
SMART JUNCTION BLOCK
TAIL ON IND
TRANSCEIVER/
WHT WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Headlamps circuit, except hybrid (2 of 2) -> FOG LAMP SW INPUT
