Kia Optima IV facelift (2018-2020) driver emergency fastening device Wiring diagram
This page shows the only wiring diagram for the component.driver emergency fastening device, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver emergency fastening device (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DRIVER EMERGENCY FASTENING DEVICE
DRIVER FRONT SIDE IMPACT SENSOR
DRIVER PRESSURE SIDE IMPACT SENSOR
DRIVER REAR SIDE IMPACT SENSOR
DRIVER SEAT BELT PRETENSIONER
GRN WIRE
GRY WIRE
PASS BUCKLE SENS (+) LOW
PASS BUCKLE SENS HIGH
PASSENGER CURTAIN AIR BAG
PASSENGER EMERGENCY FASTENING DEVICE
PASSENGER FRONT SIDE IMPACT SENSOR
PASSENGER PRESSURE SIDE IMPACT SENSOR
PASSENGER REAR SIDE IMPACT SENSOR
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
PNK WIRE
RED WIRE
SRS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, except hybrid (3 of 3) -> DRIVER EMERGENCY FASTENING DEVICE
