Kia Optima IV facelift (2018-2020) c-can transceiver low Wiring diagram
This page shows the only wiring diagram for the component.c-can transceiver low, which is found in the car Kia Optima IV facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-can transceiver low (1 of 1)
BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E I/P-D PNK WIRE
INSTRUMENT CLUSTER
MDPS 1 FUSE
MDPS FUSE
MDPS IND
MDPS UNIT
MEMORY PWR
MICOM
MULTI FUSE (TYPE A)
PNK ON/START IN WIRE
RED WIRE
S GND
SMART JUNCTION BLOCK
WHT WIRE
Go to component -> Electronic power steering circuit, except hybrid -> C-CAN TRANSCEIVER LOW
