Tire pressure monitoring circuit, except hybrid for Kia Optima IV (2015-2018)

B-CAN HIGH B-CAN LOW BCM BLK WIRE BRN WIRE C-CAN CLUSTER FUSE COMPUTER DATA LINES SYSTEM HOT IN ON OR START I/P-D I/P-E INSTRUMENT CLUSTER LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MICOM MODULE 3 FUSE ON/START INPUT RIGHT END OF DASH) RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR S GND SIG GND SMART JUNCTION BLOCK TPMS IND TRANSCEIVER/ WHT WIRE YEL WIRE
