Kia Optima IV (2015-2018) window lock switch Wiring diagrams

This page contains all the electrical diagrams for the component. window lock switch, in which he is found in the car Kia Optima IV (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram window lock switch (1 of 4)

Wiring diagram window lock switch for Kia Optima IV (2015-2018) (1 of 4)

Get access

AUTO DOWN BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CONTROL UNIT) DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER POWER WINDOW MOTOR DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A ILL IPS CONTROL MODULE LEFT POWER WINDOW RELAY LEFT REAR WINDOW SWITCH OFF ORG/ WIRE P/WINDOW LH FUSE P/WINDOW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH PWR WINDOW RELAY CONTROL RED WIRE RIGHT POWER WINDOW RELAY RIGHT REAR WINDOW SWITCH SMART JUNCTION BLOCK WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, except hybrid w/ driver auto down (1 of 2) -> WINDOW LOCK SWITCH

Wiring diagram window lock switch (2 of 4)

Wiring diagram window lock switch for Kia Optima IV (2015-2018) (2 of 4)

Get access

AUTO DOWN AUTO UP UP BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A ILL IPS CONTROL MODULE LEFT POWER WINDOW RELAY LEFT REAR WINDOW SWITCH OFF ORG/ WIRE P/WINDOW LH FUSE P/WINDOW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH PWR WINDOW RELAY CONTROL RED WIRE RIGHT POWER WINDOW RELAY RIGHT REAR WINDOW SWITCH SMART JUNCTION BLOCK WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, except hybrid w/o ims w/ driver auto up/down & safety power windows (1 of 2) -> WINDOW LOCK SWITCH

Wiring diagram window lock switch (3 of 4)

Wiring diagram window lock switch for Kia Optima IV (2015-2018) (3 of 4)

Get access

AUTO DOWN AUTO UP UP BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DOWN/ AUTO DOWN DRIVER WINDOW SWITCH GRN WIRE HOT AT ALL TIMES I/P-A ILL IPS CONTROL MODULE LEFT POWER WINDOW RELAY LEFT REAR WINDOW SWITCH OFF ORG/ WIRE P/WINDOW LH FUSE P/WINDOW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH PWR WINDOW RELAY CONTROL RED WIRE RIGHT POWER WINDOW RELAY RIGHT REAR WINDOW SWITCH SMART JUNCTION BLOCK WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, except hybrid w/o ims w/ driver/passenger auto up/down & safety power windows (1 of 2) -> WINDOW LOCK SWITCH

Wiring diagram window lock switch (4 of 4)

Wiring diagram window lock switch for Kia Optima IV (2015-2018) (4 of 4)

Get access

AUTO DOWN AUTO UP BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DOOR LOCK IND DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER WINDOW SWITCH GRN WIRE HOT AT ALL TIMES I/P-A IGPM ILL IPS CONTROL MODULE LEFT PWR WINDOW RELAY CONTROL LEFT REAR WINDOW SWITCH NCA WIRE OFF ORG/ WIRE P/WINDOW LH FUSE P/WINDOW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW LH RELAY POWER WINDOW MAIN SWITCH POWER WINDOW RH RELAY RIGHT PWR WINDOW RELAY CONTROL RIGHT REAR WINDOW SWITCH WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, hybrid w/o ims (1 of 2) -> WINDOW LOCK SWITCH
