Kia Optima IV (2015-2018) warning ind Wiring diagram
This page shows the only wiring diagram for the component.warning ind, which is found in the car Kia Optima IV (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram warning ind (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BSD IND
BSD ON/OFF SWITCH
BSD ON/OFF SWITCH IND PNK WIRE
BSD SWITCH
C-CAN HIGH
C-CAN LOW
C-CAN PR HIGH
C-CAN PR LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
EXCEPT HYBRID
EXCEPT HYBRID HYBRID EXCEPT PLUG-IN HYBRID
GRN WIRE
GROUND
HOT IN ON OR START
I/P-A
ILL
LEFT BLIND SPOT DETECTION RADAR
MODULE 4 FUSE
NCA WIRE
ON/START I/P
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PASSENGER'S DOOR
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT BLIND SPOT DETECTION RADAR
SMART JUNCTION BLOCK
WARNING IND
WHT WIRE
WHT/BLK WIRE
Go to component -> Blind spot information system circuit -> WARNING IND
