Kia Optima IV (2015-2018) vehicle spd in Wiring diagram
This page shows the only wiring diagram for the component.vehicle spd in, which is found in the car Kia Optima IV (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle spd in (1 of 1)
2.0L TURBO
2.4L
APS 1 GROUND
APS 1 POWER
APS 1 SIGNAL
APS 2 GROUND
APS 2 POWER
APS 2 SIGNAL
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SW
BRAKE TEST SW
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF
E/R-D
ECU 2 FUSE
ENTER
ETC OUTPUT (+)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
ILL
MEM POWER
ORG/ WIRE
PCB BLOCK
PCM (2.0L TURBO, 2.4L) ECM (1.6L TURBO)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT TRIP REMOTE CONTROL SWITCH
SCC
SET- RES+
STEERING WHEEL)
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS POWER
TRIP
UP DOWN GROUP
VEHICLE SPD IN
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit, except hybrid (1 of 3) -> VEHICLE SPD IN
