Kia Optima IV (2015-2018) temp gnd Wiring diagram
This page shows the only wiring diagram for the component.temp gnd, which is found in the car Kia Optima IV (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp gnd (1 of 1)
BLK WIRE
BLU WIRE
BMS ASSEMBLY
BMS CONTROL MODULE
FROM BMS CONTROL MODULE (DIAGRAM 4 OF 6)
FROM MAIN BATTERY SAFETY PLUG (DIAGRAM 5 OF 6)
GRN WIRE
GRY WIRE
MAIN BATTERY MODULE 6
MAIN BATTERY MODULE 7
MAIN BATTERY MODULE 8
MAIN BATTERY MODULE 9
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
TEMP GND
TEMP SIG
TO POWER RELAY ASSEMBLY (DIAGRAM 3 OF 6)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l hybrid, hybrid control circuit (6 of 6) -> TEMP GND
