Kia Optima IV (2015-2018) rly ctrl gnd pnk rly ctrl main- Wiring diagram

BATTERY C/FAN FUSE BATTERY C/FAN RELAY BATTERY MANAGEMENT FUSE BLK WIRE BLU WIRE BMS BLOWER MOTOR BMS CONTROL MODULE BMS ASSEMBLY BRAKE SIG BRN WIRE COMPUTER DATA LINES SYSTEM CRASH OUTPUT CURRENT SENS GND CURRENT SENS SIG E/R JUNCTION BLOCK E/R-D E/R-F FEEDBACK SIG FROM MAIN BATTERY SAFETY PLUG (DIAGRAM 5 OF 6) GRN WIRE GRN/BLK WIRE GRY WIRE H-CAN HIGH H-CAN LOW HEV ECU 2 FUSE HOT AT ALL TIMES HOT AT ALL TIMES IGPM I/P-A I/P-D I/P-E MEMORY PWR MEMORY PWR PNK ON/START INPUT WIRE MODULE 4 FUSE OPCU 1 FUSE OPCU 2 FUSE OPU STATUS ORG/ WIRE P-CAN HIGH P-CAN LOW P/N SW (P,N POSITION :SW CLOSE) PCB BLOCK PCM PNK CURRENT SENS VOUT WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PWM COMMAND PWR RED WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT END OF DASH) RLY CTRL RLY CTRL GND PNK RLY CTRL MAIN- WIRE RLY CTRL MAIN + RLY CTRL PRE SAFETY PLUG SIG SMART KEY CONTROL MODULE (RIGHT END OF DASH) SPEED START FUSE START RLY START/STOP BUTTON SWITCH SUPPLEMENTAL RESTRAINTS SYSTEM TO MAIN BATTERY SAFETY PLUG (DIAGRAM 5 OF 6) TRANSAXLE RANGE SWITCH VF (FEEDBACK) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
