Kia Optima IV (2015-2018) right rear surround speaker Wiring diagrams

This page contains all the electrical diagrams for the component. right rear surround speaker, in which he is found in the car Kia Optima IV (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right rear surround speaker (1 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (1 of 9)

Get access

ACC/ON IN AMP AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RED/ORG WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SMART JUNCTION BLOCK SPDIF GND SPDIF OUT (-) WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid & plug in hybrid version 1.0 w/ amplifier (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (2 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (2 of 9)

Get access

AUDIO BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE CALL CLOCK- SPRING DOWN DRIVER DOOR SPEAKER GRN WIRE GRN/ORG WIRE ILL LEFT AUDIO REMOTE CONTROL SWITCH LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER MODE MUTE NCA WIRE OFF ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RED/ORG WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SEEK STEERING WHEEL) VOL (-) WHT WIRE WHT/ORG WIRE WOOFER SPEAKER YEL WIRE

Go to component -> Navigation circuit, except hybrid & plug in hybrid version 4.0 & pio w/ amplifier (3 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (3 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (3 of 9)

Get access

ACC/ON IN AMP (RIGHT SIDE OF TRUNK) AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A IGPM LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NAVI VOICE (+) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SPDIF GND SPDIF OUT (-) WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid & plug in hybrid (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (4 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (4 of 9)

Get access

ACC/ON IN AMP AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RED/ORG WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SMART JUNCTION BLOCK SPDIF GND SPDIF OUT (-) WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Radio circuit, except hybrid & plug in hybrid version 1.0 w/ navigation & amplifier (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (5 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (5 of 9)

Get access

AUDIO BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE CALL CLOCK- SPRING DOWN DRIVER DOOR SPEAKER GRN WIRE GRN/ORG WIRE ILL LEFT AUDIO REMOTE CONTROL SWITCH LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER MODE MUTE NCA WIRE OFF ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RED/ORG WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SEEK STEERING WHEEL) VOL (-) WHT WIRE WHT/ORG WIRE WOOFER SPEAKER YEL WIRE

Go to component -> Radio circuit, except hybrid & plug in hybrid version 4.0 & pio w/ navigation & amplifier (3 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (6 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (6 of 9)

Get access

ACC/ON IN AMP (RIGHT SIDE OF TRUNK) AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A IGPM LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NAVI VOICE (+) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SPDIF GND SPDIF OUT (-) WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (7 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (7 of 9)

Get access

ACC/ON IN AMP (RIGHT SIDE OF TRUNK) AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A IGPM LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NAVI VOICE (+) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SPDIF GND SPDIF OUT (-) WHT WIRE YEL WIRE

Go to component -> Radio circuit, plug in hybrid w/ navigation (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (8 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (8 of 9)

Get access

ACC/ON IN AMP AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED I/P-A I/P-D IGPM LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) MODULE 2 FUSE NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER SPDIF GND SPDIF OUT (-) WHT WIRE YEL WIRE

Go to component -> Radio circuit, plug in hybrid w/o navigation & uvo w/ amplifier (4 of 4) -> RIGHT REAR SURROUND SPEAKER

Wiring diagram right rear surround speaker (9 of 9)

Wiring diagram right rear surround speaker for Kia Optima IV (2015-2018) (9 of 9)

Get access

ACC/ON IN AMP AMP FUSE BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CTR + DRIVER DOOR SPEAKER GRN WIRE HOT AT ALL TIMES I/P-A IGPM LEFT FRONT MID-RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SURROUND SPEAKER M-CAN HIGH M-CAN LOW MEM PWR MID FL (-) MID FR (-) NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER RED WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SURROUND SPEAKER WHT WIRE YEL WIRE

Go to component -> Radio circuit, plug in hybrid w/o navigation w/ uvo & amplifier (4 of 4) -> RIGHT REAR SURROUND SPEAKER
