Kia Optima IV (2015-2018) high sw in Wiring diagrams
This page contains all the electrical diagrams for the component. high sw in, in which he is found in the car Kia Optima IV (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high sw in (1 of 2)
2.0L HYBRID, 2.0L PLUG IN HYBRID
AUTO HIGH BEAM IND
AUTO LIGHT SENS
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
COMPUTER DATA LINES SYSTEM
DRL
E/R JUNCTION BLOCK
GND SIG 2
GRY WIRE
HEADLAMP
HIGH BEAM IND
HIGH SW IN
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LIGHT SW SIG
LOW BEAM IND
MICOM
MONITOR
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
NCA WIRE
ORG/ WIRE
PARKING BRAKE IND.
PNK WIRE
POWER
RED WIRE
RIGHT HEADLAMP
SIG
TAIL ON IND
TRANSCEIVER/
WHT WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Autolamps circuit, hybrid (2 of 2) -> HIGH SW IN
Wiring diagram high sw in (2 of 2)
2.0L HYBRID, 2.0L PLUG IN HYBRID
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
COMPUTER DATA LINES SYSTEM
DRL
E/R JUNCTION BLOCK
GND SIG 2
GRY WIRE
HEADLAMP
HIGH BEAM IND
HIGH SW IN
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LIGHT SW SIG
LOW BEAM IND
MICOM
MONITOR
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT HEADLAMP
TAIL ON IND
TRANSCEIVER/
WHT WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Headlamps circuit, hybrid (2 of 2) -> HIGH SW IN
