Kia Optima IV (2015-2018) deicer relay Wiring diagrams
This page contains all the electrical diagrams for the component. deicer relay, in which he is found in the car Kia Optima IV (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram deicer relay (1 of 8)
2.0L TURBO, 1.6L TURBO 2.4L 2.0L TURBO, 2.4L
ABS 1 FUSE
ABS 2 FUSE
ALT FUSE
ALTERNATOR
AMS FUSE
B+1 FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
B+5 FUSE
BATTERY
BATTERY FUSE BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COLUMN TYPE
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
DCT 1 FUSE
DCT 2 FUSE
DEICER FUSE
DEICER RELAY
E-CVVT 1 FUSE
E-CVVT RELAY
E/R JUNCTION BLOCK
ESC MODULE
FROM MDPS 1 FUSE (DIAGRAM 1 OF 10)
FROM PCB BLOCK (DIAGRAM 10 OF 10)
FROM SMART JUNCTION BLOCK (DIAGRAM 2 OF 10)
GRN WIRE
H/LAMP HI FUSE
H/LAMP HI RELAY
MDPS 1 FUSE
MDPS 2 FUSE
MDPS UNIT
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
POWER OUTLET 1 FUSE
POWER OUTLET RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
START MOTOR
START RELAY
TCM
TCM (1.6L TURBO)
TO ABS 2 FUSE (DIAGRAM 1 OF 10)
TO B+4 FUSE (DIAGRAM 1 OF 10)
TO IGNITION SWITCH (DIAGRAM 9 OF 10)
TO PCB BLOCK (DIAGRAM 10 OF 10)
TO PCB BLOCK (DIAGRAM 2 OF 10)
TO PCB BLOCK (DIAGRAM 8 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 4 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 5 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 6 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 7 OF 10)
VACUUM PUMP
VACUUM PUMP 1 FUSE
W/ EPB
W/ HID
W/ SMART KEY
W/O SMART KEY
WHT WIRE
YEL WIRE
Go to component -> 1.6l turbo, power distribution circuit (1 of 10) -> DEICER RELAY
Wiring diagram deicer relay (2 of 8)
ACC RELAY
AMS FUSE
B+4 FUSE
BATTERY SENSOR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
DEICER FUSE
DEICER RELAY
E/R JUNCTION BLOCK
E/R-A
E/R-B
E/R-C
E/R-E
E/R-F
ELECTRIC OIL PUMP UNIT
ELECTRIC PARKING BRAKE MODULE
EPB 1 FUSE
EPB 2 FUSE
FROM E/R JUNCTION BLOCK (DIAGRAM 1 OF 12)
FROM MULTI FUSE (TYPE A) (DIAGRAM 1 OF 12)
FROM MULTI FUSE (TYPE B) (DIAGRAM 1 OF 12)
FROM POWER OUTLET RELAY (DIAGRAM 1 OF 12)
FRONT POWER OUTLET 1
GRN WIRE
GRN/ORG WIRE
HEV ECU 1 FUSE
HPCU
HYBRID POWER CONTROL UNIT
NCA WIRE
OPCU 1 FUSE
ORG/BLK WIRE
PNK WIRE
POWER OUTLET 2 FUSE
POWER OUTLET 3 FUSE
REAR POWER OUTLET
RED WIRE
SMART KEY CONTROL MODULE
TO IGPM (DIAGRAM 10 OF 12)
TO IGPM (DIAGRAM 7 OF 12)
TO IGPM (DIAGRAM 9 OF 12)
W/ USB CHARGER W/O USB CHARGER
W/O WIRELESS CHARGING
WHT WIRE
YEL WIRE
Go to component -> 2.0l hybrid, power distribution circuit (2 of 12) -> DEICER RELAY
Wiring diagram deicer relay (3 of 8)
ACC RELAY
AMS FUSE
B+4 FUSE
BATTERY SENSOR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
DEICER FUSE
DEICER RELAY
E/R JUNCTION BLOCK
E/R-A
E/R-B
E/R-C
E/R-E
E/R-F
ELECTRIC OIL PUMP UNIT
ELECTRIC PARKING BRAKE MODULE
EPB 1 FUSE
EPB 2 FUSE
FROM E/R JUNCTION BLOCK (DIAGRAM 1 OF 13)
FROM MULTI FUSE (TYPE A) (DIAGRAM 1 OF 13)
FROM MULTI FUSE (TYPE B) (DIAGRAM 1 OF 13)
FROM POWER OUTLET RELAY (DIAGRAM 1 OF 13)
FRONT POWER OUTLET 1
GRN WIRE
GRN/ORG WIRE
HEV ECU 1 FUSE
HPCU
HYBRID POWER CONTROL UNIT
NCA WIRE
OPCU 1 FUSE
ORG/BLK WIRE
PCB BLOCK
PNK WIRE
POWER OUTLET 2 FUSE
POWER OUTLET 3 FUSE
REAR POWER OUTLET
RED WIRE
SMART KEY CONTROL MODULE
TO IGPM (DIAGRAM 10 OF 13)
TO IGPM (DIAGRAM 7 OF 13)
TO IGPM (DIAGRAM 9 OF 13)
TO OBC FUSE (DIAGRAM 13 OF 13)
W/ USB CHARGER W/O USB CHARGER
W/O WIRELESS CHARGING
WHT WIRE
YEL WIRE
Go to component -> 2.0l plug-in hybrid, power distribution circuit (2 of 13) -> DEICER RELAY
Wiring diagram deicer relay (4 of 8)
2.0L TURBO, 1.6L TURBO 2.4L 2.0L TURBO, 2.4L
ABS 1 FUSE
ABS 2 FUSE
ALT FUSE
ALTERNATOR
AMS FUSE
B+1 FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
B+5 FUSE
BATTERY
BATTERY FUSE BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COLUMN TYPE
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
DCT 1 FUSE
DCT 2 FUSE
DEICER FUSE
DEICER RELAY
E-CVVT 1 FUSE
E-CVVT RELAY
E/R JUNCTION BLOCK
ESC MODULE
FROM MDPS 1 FUSE (DIAGRAM 1 OF 10)
FROM PCB BLOCK (DIAGRAM 10 OF 10)
FROM SMART JUNCTION BLOCK (DIAGRAM 2 OF 10)
GRN WIRE
H/LAMP HI FUSE
H/LAMP HI RELAY
MDPS 1 FUSE
MDPS 2 FUSE
MDPS UNIT
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
POWER OUTLET 1 FUSE
POWER OUTLET RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
START MOTOR
START RELAY
TCM
TCM (1.6L TURBO)
TO ABS 2 FUSE (DIAGRAM 1 OF 10)
TO B+4 FUSE (DIAGRAM 1 OF 10)
TO IGNITION SWITCH (DIAGRAM 9 OF 10)
TO PCB BLOCK (DIAGRAM 10 OF 10)
TO PCB BLOCK (DIAGRAM 2 OF 10)
TO PCB BLOCK (DIAGRAM 8 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 4 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 5 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 6 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 7 OF 10)
VACUUM PUMP
VACUUM PUMP 1 FUSE
W/ EPB
W/ HID
W/ SMART KEY
W/O SMART KEY
WHT WIRE
YEL WIRE
Go to component -> 2.0l turbo, power distribution circuit (1 of 10) -> DEICER RELAY
Wiring diagram deicer relay (5 of 8)
2.0L TURBO, 1.6L TURBO 2.4L 2.0L TURBO, 2.4L
ABS 1 FUSE
ABS 2 FUSE
ALT FUSE
ALTERNATOR
AMS FUSE
B+1 FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
B+5 FUSE
BATTERY
BATTERY FUSE BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COLUMN TYPE
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
DCT 1 FUSE
DCT 2 FUSE
DEICER FUSE
DEICER RELAY
E-CVVT 1 FUSE
E-CVVT RELAY
E/R JUNCTION BLOCK
ESC MODULE
FROM MDPS 1 FUSE (DIAGRAM 1 OF 10)
FROM PCB BLOCK (DIAGRAM 10 OF 10)
FROM SMART JUNCTION BLOCK (DIAGRAM 2 OF 10)
GRN WIRE
H/LAMP HI FUSE
H/LAMP HI RELAY
MDPS 1 FUSE
MDPS 2 FUSE
MDPS UNIT
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
POWER OUTLET 1 FUSE
POWER OUTLET RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
START MOTOR
START RELAY
TCM
TCM (1.6L TURBO)
TO ABS 2 FUSE (DIAGRAM 1 OF 10)
TO B+4 FUSE (DIAGRAM 1 OF 10)
TO IGNITION SWITCH (DIAGRAM 9 OF 10)
TO PCB BLOCK (DIAGRAM 10 OF 10)
TO PCB BLOCK (DIAGRAM 2 OF 10)
TO PCB BLOCK (DIAGRAM 8 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 4 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 5 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 6 OF 10)
TO SMART JUNCTION BLOCK (DIAGRAM 7 OF 10)
VACUUM PUMP
VACUUM PUMP 1 FUSE
W/ EPB
W/ HID
W/ SMART KEY
W/O SMART KEY
WHT WIRE
YEL WIRE
Go to component -> 2.4l, power distribution circuit (1 of 10) -> DEICER RELAY
Wiring diagram deicer relay (6 of 8)
A/C CONTROL MODULE
AUTOMATIC A/C MANUAL A/C
B-CAN HIGH
B-CAN LOW
BCM (RIGHT END OF DASH)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DEFROST
DEICER FUSE
DEICER RELAY
DEICER RLY CONTROL
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
E/R JUNCTION BLOCK
FRONT DEICER
GRN WIRE
HEATED MIRROR FUSE
HOT AT ALL TIMES
I/P-C
I/P-E
IND
IPS CONTROL MODULE
MULTI FUSE (TYPE A)
NCA WIRE
OFF
PASSENGER POWER OUTSIDE MIRROR
PASSENGER'S DOOR
PNK (OR PNK) WIRE
PNK WIRE
PNK/BLK WIRE
REAR DEFOGGER
REAR DEFOGGER SW INPUT
REAR DEFOGGER SWITCH
REAR DEFOGGER/FRONT
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
SMART JUNCTION BLOCK
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Defoggers circuit, except hybrid -> DEICER RELAY
Wiring diagram deicer relay (7 of 8)
2.0L HYBRID
2.0L PLUG-IN HYBRID
A/C CONTROL MODULE
AIR CONDITIONING SYSTEM
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER ACTUATOR CLOSE
AUTO DEFOGGER ACTUATOR F/B
AUTO DEFOGGER ACTUATOR OPEN
AUTO DEFOGGER SENSOR
B-CAN
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DEICER FUSE
DEICER RELAY
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
E/R JUNCTION BLOCK
FRONT DEICER
GRN WIRE
GRY WIRE
HEATED MIRROR FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HUMIDITY (PWM)
I/P-C
I/P-E
IGPM
IND
IPS CONTROL MODULE
LOW HIGH
MODULE 5 FUSE
MULTI FUSE (TYPE A)
NCA WIRE
OFF
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER DOOR)
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR DEFOGGER SWITCH INPUT
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RLY CTRL
SENSOR GND
SENSOR PWR
W/ NAVIGATION W/O NAVIGATION W/ UVO
W/O NAVIGATION, UVO
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Defoggers circuit, hybrid w/ auto defogger -> DEICER RELAY
Wiring diagram deicer relay (8 of 8)
A/C CONTROL MODULE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DEICER FUSE
DEICER RELAY
DEICER RLY CONTROL
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
E/R JUNCTION BLOCK
FRONT DEICER
GRN WIRE
HEATED MIRROR FUSE
HOT AT ALL TIMES
I/P-C
I/P-E
IGPM
IND
IPS CONTROL MODULE
MULTI FUSE (TYPE A)
NCA WIRE
OFF
PASSENGER POWER OUTSIDE MIRROR
PASSENGER'S DOOR
PNK WIRE
PNK/BLK WIRE
REAR DEFOGGER
REAR DEFOGGER SW INPUT
REAR DEFOGGER SWITCH
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Defoggers circuit, hybrid w/o auto defogger -> DEICER RELAY
