Kia Optima IV (2015-2018) avm mode gnd Wiring diagram
This page shows the only wiring diagram for the component.avm mode gnd, which is found in the car Kia Optima IV (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram avm mode gnd (1 of 1)
ACC/ON IN
ANT-G
ANT-S
ANTENNA
AUDIO
AUX DETECT
AUX GND
AUX L +
AUX R +
AUX, USB JACK
AVM MODE GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BPF
BRN WIRE
CIRCUIT
COMBINATION ANTENNA
COMPUTER DATA LINES SYSTEM
GLASS ANTENNA
GPS
GRN WIRE
HOT IN ON OR START
I/P-E
ILL
M-CAN HIGH
M-CAN LOW
MATCHING CIRCUIT
MEM PWR
MIC -
MIC SHIELD
MODULE 3 FUSE
MODULE 5 FUSE
NCA WIRE
ON/ST IN
ORG/ WIRE
OUT
RADIO
RED WIRE
RED/ORG WIRE
RFC
SMART JUNCTION BLOCK
SXM
USB D-
USB GND
USB VCC
Go to component -> Radio circuit, except hybrid & plug in hybrid w/o navigation w/ display (3 of 3) -> AVM MODE GND
