Heated steering wheel circuit for Kia Optima III facelift (2013-2015)
Heated steering wheel circuit
BLK WIRE
BLU WIRE
CLOCK- SPRING
CRASH PAD SWITCH
GND NTC (+)
GND POWER
GRN WIRE
HEATER PAD
HOT IN ON
HTD STRG FUSE
I/P-E
IND
IND SWITCH
INSTRUMENT CLUSTER
JOINT CONNECTOR UMC
NTC + GND
ON INPUT GND
POWER GND
RED WIRE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
STEERING GND ON INPUT WHEEL HEATER MODULE
STEERING WHEEL HEATER MODULE
STEERING WHEEL HEATER SWITCH
STEERING WHEEL)
SWITCH
WHT WIRE
YEL WIRE
