Kia Optima III facelift (2013-2015) trip out Wiring diagrams
This page contains all the electrical diagrams for the component. trip out, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
trip out wiring diagram (1 of 4)
12 CGINJ
2.0L TURBO
2.4L
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
CGINJ
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE OUT
DES
DN SELECT
DOOR SW
GRN WIRE
GRY WIRE
HIGH LOW
HOT IN ACC OR ON
I/P-B
I/P-E
I/P-G
ILL
ILL ILL
IPS CONTROL MODULE
LOW HIGH
MODULE 1 FUSE
OIL PRESSURE SWITCH
OIL PRESSURE SWITCH (LEFT SIDE OF ENGINE)
ORG/ WIRE
PNK 8 10 WIRE
PNK WIRE
RED WIRE
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
SELECT
SET- CANCEL RES+
SET- RES+
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
STEERING WHEEL)
TRIP
TRIP (+) TRIP (-)
TRIP OUT
TRIP OUT OUT
TRIP(-) (-) CRUISE IN/ TRIP IN
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit, except hybrid korean made (2 of 4) -> TRIP OUT
trip out wiring diagram (2 of 4)
-SET CANCEL
12 CGINJ
2.0L TURBO
2.4L
BLK WIRE
BLU WIRE
BRN WIRE
CGINJ
CLOCKSPRING
CRUISE
CRUISE ON/OFF
CRUISE OUT
CRUISE TRIP (+) OUT OUT
DES
DN SELECT
DOOR SW
GRN WIRE
GRY WIRE
I/P-B
ILL
IPS CONTROL MODULE
OIL PRESSURE SWITCH (LEFT SIDE OF ENGINE)
ORG/ WIRE
PNK 8 10 WIRE
PNK WIRE
RES+
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
SELECT
SET- CANCEL RES+ TRIP
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
STEERING WHEEL)
TRIP
TRIP (+) TRIP (-)
TRIP OUT
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, except hybrid usa made (3 of 4) -> TRIP OUT
trip out wiring diagram (3 of 4)
ACT ECO IN
BLK ORG/ WIRE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
C-CAN TRANSCEIVER
CHECK ENGINE IND
CLOCK- SPRING
CLUSTER FUSE
CLUSTER FUSE (ABOVE LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE OUT
CRUISE TRIP (+) OUT OUT
DES
DN SELECT
ECO IND
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HIGH LOW
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START SMART JUNCTION BOX
I/P-E
I/P-F
ILL
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER S-GND
LEAK CURRENT AUTOCUT DEVICE
MEMORY 1 FUSE
MICOM
ORG/ WIRE
PNK 8 10 WIRE
PNK 8 9 10 11 12 13 WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
REG
RES+
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
S GND
SELECT DN
SET-
SET- CANCEL RES+ TRIP
SMART JUNCTION BOX
TRIP
TRIP (+) TRIP (-)
TRIP OUT
TRIP SW(-)
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (5 of 6) -> TRIP OUT
trip out wiring diagram (4 of 4)
10 11 12 PNK WIRE
ACT ECO IN
BLK ORG/ WIRE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
C-CAN TRANSCEIVER
CHECK ENGINE IND
CLOCKSPRING
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE OUT
CRUISE TRIP (+) OUT OUT
DES
ECO IND
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HIGH LOW
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START SMART JUNCTION CLUSTER BOX FUSE (ABOVE LEFT KICK PANEL)
I/P-E
I/P-F
ILL
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER S-GND
LEAK CURRENT AUTOCUT DEVICE
MCU
MEMORY 1 FUSE
ORG/ WIRE
PNK 7 8 9 10 11 12 WIRE
PNK 7 8 9 WIRE
PNK 8 10 WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
REG
RES+
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
S GND
SELECT DN
SET-
SET- CANCEL RES+ TRIP
SMART JUNCTION BOX
STEERING WHEEL)
TRIP
TRIP (+) TRIP (-)
TRIP OUT
TRIP SW(-)
UP DN SELECT
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.4l (5 of 6) -> TRIP OUT
