Kia Optima III facelift (2013-2015) stp lamp sw memory pwr stp lamp 5 8 4 Wiring diagrams
This page contains all the electrical diagrams for the component. stp lamp sw memory pwr stp lamp 5 8 4, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stp lamp sw memory pwr stp lamp 5 8 4 (1 of 2)
2.0L TURBO
2.4L
29 30 HI LO
31 32 LO HI
4 1 PNK WIRE
7 8 C-CAN HIGH C-CAN LOW
ABS IND.
AUTO HOLD (WHITE/ YELLOW/ GREEN) IND
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE IND
BRAKE SWITCH FUSE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
CONTROL
E/R FUSE, RELAY BOX
ELECTRIC PARKING BRAKE MODULE
ELECTRIC PARKING BRAKE MODULE (LEFT END OF DASH)
ESC 1 FUSE
ESC 1 FUSE ESC 3 FUSE
ESC 2 FUSE
ESC 3 FUSE
ESC IND
ESC OFF IND
ESC OFF IND ESC ABS IND IND
ESS SIG
ESS SIG HAC SIG 3 2
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HAC SIG
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
INPUT CIRCUIT
INSTRUMENT CLUSTER
INTERNAL
INTERNAL CONTROL
IPS
LEFT FRONT WHEEL SENSOR
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR
LEFT REAR WHEEL SENSOR (ON LEFT REAR WHEEL HUB ASSEMBLY)
MDPS UNIT (BASE OF STEERING COLUMN)
MEMORY PWR
MICOM
MULTI FUSE
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
SMART KEY CONTROL MODULE (RIGHT END OF DASH)
STOP (LEFT SIDE LAMP OF ENGINE FUSE COMPT)
STOP LAMP FUSE
STP LAMP PNK WIRE
STP LAMP SIG
STP LAMP SW 5 8
STP LAMP SW MEMORY PWR STP LAMP 5 8 4
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit, except hybrid korean made (2 of 2) -> STP LAMP SW MEMORY PWR STP LAMP 5 8 4
Wiring diagram stp lamp sw memory pwr stp lamp 5 8 4 (2 of 2)
2.0L TURBO
2.4L
29 30 HI LO
31 32 LO HI
4 1 PNK WIRE
ABS IND.
AUTO HOLD (WHITE/ YELLOW/ GREEN) IND
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE BOX SWITCH (ABOVE FUSE LEFT KICK PANEL)
BRAKE IND
BRAKE SWITCH FUSE
BRN WIRE
C-CAN HIGH
C-CAN HIGH C-CAN LOW
C-CAN LOW
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
CONTROL
E/R FUSE, RELAY BOX
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ELECTRIC PARKING BRAKE MODULE
ELECTRIC PARKING BRAKE MODULE (LEFT END OF DASH)
ESC 1 FUSE
ESC 2 FUSE
ESC 3 FUSE
ESC IND
ESC OFF IND
ESC OFF IND ESC ABS IND IND
ESS SIG
ESS SIG HAC SIG 3 2
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HAC SIG
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
INPUT CIRCUIT
INSTRUMENT CLUSTER
INTERNAL
INTERNAL CONTROL
IPS
LEFT FRONT WHEEL SENSOR
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR
LEFT REAR WHEEL SENSOR (ON LEFT REAR WHEEL HUB ASSEMBLY)
MDPS UNIT (BASE OF STEERING COLUMN)
MEMORY PWR
MICOM
MULTI FUSE
MULTI FUSE ESC 1 FUSE ESC 3 FUSE
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
SMART JUNCTION
SMART JUNCTION BOX
SMART KEY CONTROL MODULE (RIGHT END OF DASH)
STOP LAMP FUSE
STP LAMP PNK WIRE
STP LAMP SIG
STP LAMP SW 5 8
STP LAMP SW MEMORY PWR STP LAMP 5 8 4
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit, except hybrid usa made (2 of 2) -> STP LAMP SW MEMORY PWR STP LAMP 5 8 4
