Kia Optima III facelift (2013-2015) smart key trunk antenna wiring diagram
This page shows the only wiring diagram for the component.smart key trunk antenna, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
smart key trunk antenna wiring diagram (1 of 1)
A/T
ANT GND
ANT PWR
B-CAN TRANSCEIVER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY/ORG WIRE
IGNITION LOCK SWITCH
IMMO IND
INSTRUMENT CLUSTER
M/T
MICOM
ORG/ WIRE
ORG/BLK WIRE
P POSITION SWITCH
POWER
POWER ANT PWR
RED WIRE
RED/ORG WIRE
RIGHT END OF DASH)
SMART KEY ANTENNA 1
SMART KEY ANTENNA 2
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE
SMART KEY TRUNK ANTENNA
SPORT MODE SWITCH
SSB GREEN
SSB ILL GND
SSB ILL POWER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, w/ smart key system (3 of 3) -> SMART KEY TRUNK ANTENNA
