Kia Optima III facelift (2013-2015) smart key overhead control console lamp module Wiring diagram
This page shows the only wiring diagram for the component.smart key overhead control console lamp module, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram smart key overhead control console lamp module (1 of 1)
2.0L TURBO 2.4L
3.0
4.0
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
AMP
AUDIO
AUTOMATIC A/C
BCM
BCM TELEMATICS UNIT
BLK WIRE
BLU WIRE
C/LIGHTER FUSE
CIGAR LIGHTER
CLOCK
CRASH PAD MOOD LAMP
DRIVER DOOR MOOD LAMP
ECU 4 FUSE
ESC 3 FUSE
ESC MODULE
FROM ACC RELAY (DIAGRAM 2 OF 10)
FROM IGNITION SWITCH (DIAGRAM 9 OF 10)
FROM SMART JUNCTION BOX (DIAGRAM 2 OF 10)
FRONT POWER OUTLET
I/P-A
I/P-E
MANUAL A/C
MODULE 1 FUSE
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PASSENGER DOOR MOOD LAMP
PCM
PNK WIRE
PNK/BLK WIRE
POWER OUTLET FUSE
POWER OUTSIDE MIRROR SWITCH
SMART KEY CONTROL MODULE
SMART KEY OVERHEAD CONTROL CONSOLE LAMP MODULE
TCU 2 FUSE
TELEMATICS UNIT
TRANSAXLE RANGE SWITCH
W/ NAVIGATION
W/ SMART KEY
W/ UVO
W/O NAVIGATION
W/O SMART KEY
W/O UVO
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (8 of 10) -> SMART KEY OVERHEAD CONTROL CONSOLE LAMP MODULE
