Kia Optima III facelift (2013-2015) smart junction box (above left kick Wiring diagram
This page shows the only wiring diagram for the component.smart junction box (above left kick, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram smart junction box (above left kick (1 of 1)
10 WAY 2 WAY
AMP
AMP FUSE
AUTO HEADLAMP LEVELING DEVICE MODULE
BLK/WHT WIRE
BLU/ORG WIRE
CTRL
DRIVER DRIVER SEAT LUMBAR MANUAL SUPPORT SWITCH SWITCH
DRIVER IMS MODULE
DRIVER LUMBAR SUPPORT SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER SEAT MANUAL SWITCH
FROM IPS 4 (DIAGRAM 4 OF 9)
FROM MULTI FUSE (DIAGRAM 1 OF 9)
GRN WIRE
I/P-A
I/P-C
I/P-D
I/P-F
IPS 3
IPS 3 CTRL
IPS 5
IPS 5 CTRL
IPS CONTROL MODULE
IPS CONTROL MODULE CTRL
J/C
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT REAR COMBINATION LAMP (OUT)
LEFT RIGHT FRONT FRONT FOG FOG LAMP LAMP
NCA WIRE
ORG/ WIRE
P/SEAT (DRV) FUSE
P/SEAT PASS FUSE
PANEL)
PASSENGER POWER OUTSIDE MIRROR
PASSENGER SEAT MANUAL SWITCH
PDM 2 FUSE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP (OUT)
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK
STOP BUTTON SWITCH (DIAGRAM 2 OF 9)
TO IPS 5 (DIAGRAM 4 OF 9)
TO IPS 6 (DIAGRAM 5 OF 9)
TO SMART KEY CONTROL MODULE (DIAGRAM 2 OF 9)
TO START STOP BUTTON SWITCH (DIAGRAM 2 OF 9)
W/ DRL
W/ HID
W/ MEMORY
W/O HID
W/O MEMORY
YEL WIRE
Go to component -> Power distribution circuit, hybrid (4 of 9) -> SMART JUNCTION BOX (ABOVE LEFT KICK
