Kia Optima III facelift (2013-2015) set- cancel res+ Wiring diagrams
This page contains all the electrical diagrams for the component. set- cancel res+, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram set- cancel res+ (1 of 2)
12 CGINJ
2.0L TURBO
2.4L
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
CGINJ
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE OUT
DES
DN SELECT
DOOR SW
GRN WIRE
GRY WIRE
HIGH LOW
HOT IN ACC OR ON
I/P-B
I/P-E
I/P-G
ILL
ILL ILL
IPS CONTROL MODULE
LOW HIGH
MODULE 1 FUSE
OIL PRESSURE SWITCH
OIL PRESSURE SWITCH (LEFT SIDE OF ENGINE)
ORG/ WIRE
PNK 8 10 WIRE
PNK WIRE
RED WIRE
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
SELECT
SET- CANCEL RES+
SET- RES+
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
STEERING WHEEL)
TRIP
TRIP (+) TRIP (-)
TRIP OUT
TRIP OUT OUT
TRIP(-) (-) CRUISE IN/ TRIP IN
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit, except hybrid korean made (2 of 4) -> SET- CANCEL RES+
Wiring diagram set- cancel res+ (2 of 2)
-SET CANCEL
3.0
4.0
A/V, NAVIGATION HEAD UNIT
B-CAN
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE FLUID LEVEL SENSOR (ON BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE TRIP
DES
DN SELECT
DRIVER DOOR SWITCH
DRIVER DOOR SWITCH (LEFT "B" PILLAR)
DRV DR SW
FOOT PARKING BRAKE SWITCH
FOOT PARKING BRAKE SWITCH (BASE OF PARKING BRAKE ASSEMBLY)
FUEL
FUEL SENDER
GRN WIRE
GRY WIRE
HIGH LOW
HOT IN ON OR ACC
I/P-B
I/P-D
I/P-E
I/P-E I/P-G
I/P-G
ILL
ILL ILL
IPS CONTROL MODULE
KICK PANEL)
LEFT "C" PILLAR)
LEFT REAR DOOR SWITCH
LEFT REAR DOOR SWITCH (LEFT "C" PILLAR)
LOW HIGH
MODULE 1 FUSE
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PASS DR SW
PASSENGER DOOR SWITCH
PASSENGER DOOR SWITCH (RIGHT "B" PILLAR)
PCM
PCM (LEFT SIDE OF ENGINE COMPT)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RES+
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT REAR DOOR SWITCH
RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR)
RIGHT TRIP REMOTE CONTROL SWITCH
RL DR SW
RR DR SW
SELECT
SENDER
SET- CANCEL RES+
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT
STEERING WHEEL)
TRIP
TRIP OUT CRUISE OUT
TRIP UP
TRIP(-) (-) CRUISE IN/ TRIP IN
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit, hybrid (2 of 3) -> SET- CANCEL RES+
