Kia Optima III facelift (2013-2015) position switch code Wiring diagrams
This page contains all the electrical diagrams for the component. position switch code, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram position switch code (1 of 2)
BATTERY
BATTERY GROUND
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BURGLAR ALARM RELAY (LEFT END OF DASH)
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/P-E
I/P-G
IGN 2 FUSE
IGNITION SWITCH
IPS CONTROL MODULE BURGLAR ALARM RELAY CONTROL
LOCK
MOTOR
MULTI FUSE
ON/START INPUT
ORG/ WIRE
P/N SW
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
POSITION SWITCH CODE
RED WIRE
RELAY
SIG 1 SIG 2
SIG 3 SIG 4
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
SOLENOID
STARTER MTR CTRL SW
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
YEL WIRE
Go to component -> Starting circuit, without smart key system -> POSITION SWITCH CODE
Wiring diagram position switch code (2 of 2)
BATTERY
BATTERY GROUND
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BURGLAR ALARM RELAY
BURGLAR ALARM RELAY CONTROL
E/R FUSE, RELAY BOX
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/P-E
I/P-G
IGN 2 FUSE
IGNITION SWITCH
IPS CONTROL MODULE
LOCK
MOTOR
MULTI FUSE
ON/START INPUT
ORG/ WIRE
P/N SW
PCM
PNK WIRE
POSITION SWITCH CODE
RED WIRE
SIG (1)
SIG (2)
SIG 3
SIG 4
SMART JUNCTION BOX
START FUSE
START MOTOR
START RELAY
START SOLENOID
STARTER MTR CTRL SW
TCU 2 FUSE
TRANSAXLE RANGE SWITCH
YEL WIRE
Go to component -> Starting circuit, w/o smart key system -> POSITION SWITCH CODE
