Kia Optima III facelift (2013-2015) opcu fuse Wiring diagrams
This page contains all the electrical diagrams for the component. opcu fuse, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
opcu fuse wiring diagram (1 of 2)
AHB 1 FUSE
AHB 2 FUSE
AHB 3 FUSE
AHB 3 TCU 2 FUSE FUSE
ALT FUSE
B+1 ECU 2 FUSE FUSE
B+1 FUSE
B+2 FUSE
B+3 FUSE
BATTERY
BATTERY C/FAN FUSE
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BMS ASSEMBLY
BMS BLOWER MOTOR RELAY
BMS CONTROL MODULE
BMS EWP INVERTER FUSE FUSE FUSE
BMS FUSE
C/FAN FUSE
C/FAN HI RELAY
DEICER FUSE
DEICER RELAY
ECU 2 FUSE
ECU 4 FUSE
ELECTRIC OIL PUMP UNIT
ELECTRIC PARKING BRAKE MODULE
EPB 1 FUSE
EPB 2 FUSE
EPB-1 EPB-2 FUSE FUSE
EWP FUSE
EWP RELAY
FROM E/R FUSE, RELAY BOX (DIAGRAM 1 OF 9)
FROM MDPS FUSE (DIAGRAM 1 OF 9)
FROM MDPS FUSE (DIAGRAM 1 OF 9) STOP LAMP FUSE
FROM OPCU 2 FUSE (DIAGRAM 1 OF 9)
FROM SMART JUNCTION BOX (DIAGRAM 2 OF 9)
GRN WIRE
HEV ECU FUSE
HYBRID CONTROL UNIT
HYBRID FUSE, RELAY BOX
HYBRID FUSE, RELAY BOX FROM OPCU 2 FUSE (DIAGRAM 1 OF 9)
HYBRID POWER CONTROL UNIT
HYBRID WATER PUMP
IG 1 FUSE
IG 2 FUSE
INTEGRATED BRAKE ACTUATION UNIT
INVERTER FUSE
MCU
MCU BMS CONTROL HYBRID POWER MODULE CONTROL UNIT
MDPS FUSE
MDPS UNIT
MULTI FUSE
MULTIPURPOSE CHECK CONNECTOR
OPCU 1 FUSE
OPCU 2 FUSE
OPCU C/FAN FUSE FUSE
OPCU FUSE
OPCU RELAY
ORG/ WIRE
PCM
PCM ELECTRIC OIL PUMP UNIT
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY (DIAGRAM 2 OF 9)
RR HTD FUSE
RR HTD RELAY
STOP LAMP FUSE
STOP SIGNAL ELECTRONIC MODULE
TCU 1 FUSE
TCU 2 FUSE
TO EMS BOX (DIAGRAM 6 OF 9)
TO HYBRID FUSE, RELAY BOX (DIAGRAM 1 OF 9)
TO INVERTER FUSE (DIAGRAM 2 OF 9)
TO INVERTER FUSE (DIAGRAM 2 OF 9) TCU 1 FUSE
TO LOW VOLTAGE DC-DC CONVERTER (DIAGRAM 2 OF 9)
TO LOW VOLTAGE DC-DC CONVERTER (DIAGRAM 2 OF 9) BMS ASSEMBLY
TO OPCU RELAY (DIAGRAM 1 OF 9)
TO PDM 2
TO PDM 3
TO SMART JUNCTION BOX (DIAGRAM 4 OF 9)
TO SMART JUNCTION BOX (DIAGRAM 5 OF 9)
TO SMART JUNCTION BOX (DIAGRAM 7 OF 9)
TO SMART TO EMS BOX JUNCTION BOX (DIAGRAM (DIAGRAM 6 OF 9) 7 OF 9)
TO STOP LAMP FUSE (DIAGRAM 1 OF 9)
TRANSAXLE INTEGRATED RANGE BRAKE SWITCH ACTUATION UNIT
TRANSAXLE RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 9) -> OPCU FUSE
opcu fuse wiring diagram (2 of 2)
ATM SOLENOID (TOP OF TRANSAXLE)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BOX)
BRN WIRE
CAMSHAFT POSITION SENSOR 1
CAMSHAFT POSITION SENSOR 1 (LEFT REAR OF ENGINE)
DATA I/O
E/R FUSE, RELAY BOX
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES SMART JUNCTION MODULE 7 FUSE BOX (ABOVE LEFT KICK PANEL)
HOT IN ON OR START
HOT IN ON OR START E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE OPCU 2 FUSE COMPT)
HYBRID FUSE, RELAY
HYBRID FUSE, RELAY BOX
I/P-A
I/P-D
INPUT SPEED SENSOR
INPUT SPEED SENSOR ATM SOLENOID (TOP OF TRANSAXLE)
JOINT CONNECTOR
JOINT CONNECTOR UMC
LEFT "C" PILLAR)
MODULE 3 FUSE
MODULE 7 FUSE
NATURAL VACUUM LEAK DETECTION
NCA WIRE
OIL CONTROL VALVE 2
OIL CONTROL VALVE 2 (RIGHT FRONT OF ENGINE)
OPCU 1 FUSE
OPCU 1 FUSE TCU 1 FUSE
OPCU 2 FUSE
OPCU FUSE
OPCU RELAY
ORG/ WIRE
OUTPUT SPEED SENSOR
OXYGEN SENSOR (DOWN)
PNK 1 2 3 WIRE
PNK WIRE
PNK/BLK WIRE
POWER
RED WIRE
RED/BLK WIRE
SMART JUNCTION BOX
STOP LAMP SWITCH
STOP LAMP SWITCH (BASE OF BRAKE PEDAL ASSEMBLY)
TCU 1 FUSE
TCU 2 FUSE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.4l hybrid, mfi control circuit (4 of 5) -> OPCU FUSE
