Kia Optima III facelift (2013-2015) memory power on/start input c-can high c-can low ground Wiring diagram
This page shows the only wiring diagram for the component.memory power on/start input c-can high c-can low ground, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory power on/start input c-can high c-can low ground (1 of 1)
BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-F
INSTRUMENT CLUSTER
LEAK CURRENT AUTOCUT DEVICE
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MEMORY 1 FUSE
MEMORY POWER
MEMORY POWER ON/START INPUT C-CAN HIGH C-CAN LOW GROUND
MICOM
MODULE 3 FUSE
ON/START INPUT
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
S GND
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
TIRE PRESSURE MONITORING MODULE
TIRE PRESSURE MONITORING MODULE (RIGHT END OF DASH)
TPMS IND
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> MEMORY POWER ON/START INPUT C-CAN HIGH C-CAN LOW GROUND
