Kia Optima III facelift (2013-2015) lin diagnostic data line alternator com Wiring diagram
This page shows the only wiring diagram for the component.lin diagnostic data line alternator com, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin diagnostic data line alternator com (1 of 1)
2.0L 2.4L TURBO
2.0L TURBO
2.4L
ALT FUSE
ALTERNATOR
ALTERNATOR COM
ALTERNATOR FR
AMS FUSE
BATTERY
BATTERY GROUND
BATTERY SENSOR
BATTERY SNSR SENSOR (W/ AMS) (NEGATIVE LIN BATTERY LINE TERMINAL)
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN/ORG WIRE
CHARGE IND
CLUSTER FUSE
COM
COM FR
COMPT)
E/R FUSE, RELAY BOX
E/R FUSE, RELAY BOX AMS FUSE (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT IN ON OR START
I/P-E
INSTRUMENT CLUSTER
LIN DIAGNOSTIC DATA LINE
LIN DIAGNOSTIC DATA LINE ALTERNATOR COM
LIN LINE
MICOM
ORG/ WIRE
PCM
PCM (LEFT SIDE OF ENGINE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
SNSR
WHT WIRE
YEL/ORG WIRE
Go to component -> Charging circuit -> LIN DIAGNOSTIC DATA LINE ALTERNATOR COM
