Kia Optima III facelift (2013-2015) glove rf box receiver lamp Wiring diagrams
This page contains all the electrical diagrams for the component. glove rf box receiver lamp, in which he is found in the car Kia Optima III facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram glove rf box receiver lamp (1 of 2)
2.0L TURBO 2.4L
B/A HORN RELAY
BLU/ORG WIRE
BRAKE SWITCH FUSE
DRIVER DOOR SCUFF LAMP
E/R FUSE, RELAY BOX
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
E/R-A
E/R-B
E/R-EMS
ECU 3 FUSE
EMS BOX
FROM ECU 2 FUSE (DIAGRAM 1 OF 10)
FROM IPS 2
FROM IPS 2 (DIAGRAM 5 OF 10)
FROM IPS 7 FUSE (DIAGRAM 6 OF 10)
GLOVE BOX LAMP)
GLOVE RF BOX RECEIVER LAMP
GRY WIRE
HORN FUSE
HORN RELAY
I/P-A
I/P-D
I/P-E
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
INTERIOR LAMP FUSE
IPS 1
IPS 1 CTRL
IPS 7
IPS 7 CTRL
IPS CONTROL MODULE
LEAK CURRENT AUTOCUT DEVICE
LEAK CURRENT AUTOCUT RELAY
LEAK CURRENT AUTOCUT RLY CTRL
LEAK CURRENT AUTOCUT SW CTRL
LEAK CURRENT AUTOCUT SWITCH
LEAK ON CURRENT AUTOCUT SWITCH
LEFT HEADLAMP
LEFT RIGHT VANITY VANITY LAMP LAMP
LEFT VANITY LAMP
MEMORY 2 FUSE
NCA WIRE
OFF
OFF ON
OVERHEAD CONSOLE LAMP
PASSENGER DOOR SCUFF LAMP
PCM
PNK WIRE
REAR PERSONAL LAMP
RED WIRE
RED/ORG WIRE
RF RECEIVER
RIGHT HEADLAMP
RIGHT VANITY LAMP
ROOM LAMP
ROOM OVERHEAD LAMP CONSOLE LAMP
SMART KEY CONTROL MODULE
STOP LAMP SWITCH
TO ECU 1 FUSE (DIAGRAM 10 OF 10)
TO LEAK CURRENT AUTOCUT DEVICE RELAY (DIAGRAM 6 OF 10)
TO MEMORY 1 FUSE (DIAGRAM 7 OF 10)
TRUNK ROOM LAMP
W/ REAR PERSONAL LAMP
W/ SMART KEY
W/O REAR PERSONAL LAMP
W/O SMART KEY
Go to component -> Power distribution circuit, except hybrid (6 of 10) -> GLOVE RF BOX RECEIVER LAMP
Wiring diagram glove rf box receiver lamp (2 of 2)
B/A HORN RELAY
BLU/ORG WIRE
BMS ASSEMBLY
BMS CONTROL MODULE
BMS FUSE
BRAKE SWITCH FUSE
BRN WIRE
DRIVER DOOR SCUFF LAMP
DRIVER LEFT SMART VANITY KEY LAMP OUTSIDE HANDLE
DRIVER PASSENGER DOOR DOOR SCUFF SCUFF LAMP LAMP
DRIVER SMART KEY OUTSIDE HANDLE
E/R FUSE, RELAY BOX
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
E/R-A
E/R-B
E/R-EMS
ECU 3 FUSE
EMS BOX
FROM BMS FUSE (DIAGRAM 6 OF 9)
FROM EUC 2 FUSE (DIAGRAM 1 OF 9)
FROM IPS 2
FROM IPS 2 (DIAGRAM 5 OF 9)
GLOVE BOX LAMP)
GLOVE RF BOX RECEIVER LAMP
GRN WIRE
GRY WIRE
HORN FUSE
HORN RELAY
I/P-A
I/P-D
I/P-E
I/P-F
INTERIOR LAMP FUSE
IPS 1
IPS 1 CTRL
IPS 7
IPS 7 CTRL
IPS CONTROL MODULE
LEAK CURRENT AUTOCUT DEVICE
LEAK CURRENT AUTOCUT DEVICE RELAY
LEAK CURRENT AUTOCUT RLY CTRL
LEAK CURRENT AUTOCUT SW CTRL
LEAK CURRENT AUTOCUT SWITCH
LEAK ON CURRENT AUTOCUT SWITCH
LEFT HEADLAMP
LEFT VANITY LAMP
MEMORY 2 FUSE
NCA WIRE
OFF
OFF ON
OVERHEAD CONSOLE LAMP
PASSENGER DOOR SCUFF LAMP
PASSENGER SMART KEY OUTSIDE HANDLE
PCM
PNK WIRE
PNK/BLK WIRE
REAR PERSONAL LAMP
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RF RECEIVER
RIGHT HEADLAMP
RIGHT VANITY LAMP
ROOM LAMP
ROOM RIGHT OVERHEAD LAMP VANITY CONSOLE LAMP LAMP
SMART KEY CONTROL MODULE
STOP LAMP SWITCH
TO ECU 1 FUSE (DIAGRAM 9 OF 9)
TO LEAK CURRENT AUTOCUT DEVICE RELAY (DIAGRAM 6 OF 9)
TO MEMORY 1 FUSE (DIAGRAM 7 OF 9)
TRUNK ROOM LAMP
W/ HID
W/ REAR PERSONAL LAMP
W/O HID
W/O REAR PERSONAL LAMP
YEL WIRE
Go to component -> Power distribution circuit, hybrid (6 of 9) -> GLOVE RF BOX RECEIVER LAMP
