Kia Optima III facelift (2013-2015) front power cigar outlet lighter wiring diagram
This page shows the only wiring diagram for the component.front power cigar outlet lighter, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front power cigar outlet lighter wiring diagram (1 of 1)
A/C CONTROL MODULE
ATM GLOVE LEVER BOX LAMP INDICATOR SWITCH
ATM LEVER INDICATOR
AUTO HEADLAMP LEVELING DEVICE MODULE
BCM
BLK WIRE
BRN WIRE
CIGAR LIGHTER
CLOCK- SPRING
CRASH PAD MOOD LAMP
CRASH PAD SWITCH
DATA LINK CONNECTOR
DOOR LOCK RELAY
DOOR UNLOCK RELAY
ELECTRO- CHROMIC MIRROR
ENGINE COOLANT TEMPERATURE SENSOR
FRONT POWER CIGAR OUTLET LIGHTER
FRONT POWER OUTLET
GLOVE BOX LAMP/ SWITCH
I/P-E
I/P-F
INSTRUMENT CLUSTER
IPS CONTROL MODULE
JOINT CONNECTOR UMC
JOINT CONNECTOR UMD
JOINT CONNECTOR URA
LEFT HEADLAMP LEVELING DEVICE ACTUATOR
LEFT VANITY LAMP
MULTI- FUNCTION SWITCH
OUTSIDE MIRROR AUTO FOLDING RELAY
OUTSIDE MIRROR AUTO UNFOLDING RELAY
OVERHEAD CONSOLE LAMP
OVERHEAD CONSOLE PANORAMA SUNROOF PANORAMA SUNROOF SWITCH
OVERHEAD CONSOLE PANORAMA SUNROOF SWITCH
PANORAMA SUNROOF
RAIN SENSOR
REAR PERSONAL LAMP
REAR PERSONAL LAMP ELECTRO- CHROMIC MIRROR
RHEOSTAT
RIGHT HEADLAMP LEVELING DEVICE ACTUATOR
RIGHT LEFT VANITY VANITY LAMP LAMP
RIGHT VANITY LAMP
ROOM LAMP
SMART JUNCTION BOX
SMART KEY CONTROL MODULE
START STOP BUTTON SWITCH
STEERING WHEEL STEERING WHEEL HEATER MODULE
STOP BUTTON SWITCH
STOP SIGNAL ELECTRONIC MODULE
TELLTALE LAMP
TWO CRASH TURN PAD UNLOCK SWITCH RELAY
TWO TURN UNLOCK RELAY
W/ REAR PERSONAL LAMP
W/ REAR W/O REAR PERSONAL PERSONAL LAMP LAMP
W/O RAIN SENSOR
W/O REAR PERSONAL LAMP
YEL WIRE
Go to component -> Ground distribution circuit, hybrid (1 of 4) -> FRONT POWER CIGAR OUTLET LIGHTER
