Kia Optima III facelift (2013-2015) feedback signal Wiring diagram
This page shows the only wiring diagram for the component.feedback signal, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram feedback signal (1 of 1)
BATTERY
BATTERY GROUND
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BRN/ORG WIRE
E/R FUSE, RELAY BOX
FEEDBACK SIGNAL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-E
I/P-F
IGN 2 FUSE
MOTOR
MULTI FUSE
ORG/ WIRE
P/N SW (TOP OF TRANSAXLE)
PCM
PDM 2 FUSE
POSITION SWITCH)
POWER DISTRIBUTION SYSTEM
PWR
RED WIRE
RELAY
RIGHT END OF DASH)
RLY MOTOR CTRL CTRL SW
SMART JUNCTION BOX
SMART KEY CONTROL MODULE
SSB
START FUSE
START MOTOR
START RELAY
START SOLENOID
START STOP BUTTON SWITCH
TRANSAXLE RANGE SWITCH
TRANSMISSIONS SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Starting circuit, w/ smart key system -> FEEDBACK SIGNAL
