Kia Optima III facelift (2013-2015) exterior lights defogger system system Wiring diagram
This page shows the only wiring diagram for the component.exterior lights defogger system system, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior lights defogger system system (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BSD INDICATOR
DOWN
DRIVER POWER OUTSIDE MIRROR
EXTERIOR LIGHTS DEFOGGER SYSTEM SYSTEM
FOLDING MOTOR
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN ACC OR ON
I/P-A
JOINT CONNECTOR UDA
JOINT CONNECTOR UMC
LEFT
LEFT DOWN/ LEFT
LEFT RIGHT
LEFT/ RIGHT RIGHT
MIRROR FOLDING SWITCH
MODULE 1 FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR
OUTSIDE MIRROR AUTO UNFOLDING RELAY
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RED/ORG WIRE
SELECTOR SWITCH RIGHT
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
TURN LAMP DEFOGGER UP/ DOWN
UP DOWN
UP/ RIGHT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirror circuit, with auto folding (1 of 2) -> EXTERIOR LIGHTS DEFOGGER SYSTEM SYSTEM
