Kia Optima III facelift (2013-2015) driver seat switch wiring diagram
This page shows the only wiring diagram for the component.driver seat switch, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver seat switch wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT SWITCH
DRIVER'S CUSHION WARMER
DRIVER'S SEAT WARMER MODULE
FRONT SEAT WARMER, CCS SWITCH
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HIGH IND
HOT AT ALL TIMES
HOT IN ON OR START
HTD SW SIG
HTD(-)
I/P-A
I/P-F
LOW HIGH
LOW IND
MEMORY POWER
MODULE 4 FUSE
NCA WIRE
NTC-
ON/START INPUT
PASSENGER CUSHION WARMER
PASSENGER HIGH SEAT SWITCH
PASSENGER SEAT SWITCH
PASSENGER SEAT WARMER MODULE
PNK WIRE
RED WIRE
RED/ORG WIRE
RED/YEL WIRE
S/HEATER (FRT)/ SEAT VENT (FRT) FUSE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
SWITCH
SWITCH LOW
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Front heated seats circuit -> DRIVER SEAT SWITCH
