Kia Optima III facelift (2013-2015) crash front pad seat switch warmer, ccs switch wiring diagram
This page shows the only wiring diagram for the component.crash front pad seat switch warmer, ccs switch, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
crash front pad seat switch warmer, ccs switch wiring diagram (1 of 1)
3.0
4.0
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
ATM LEVER INDICATOR
AUDIO
AUTOMATIC A/C
AUX, USB JACK
AUX, USB JACK (W/ NAVIGATION)
BLU ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
CLOCK
CLOCK- SPRING
CRASH FRONT PAD SEAT SWITCH WARMER, CCS SWITCH
CRASH PAD SWITCH
CUP 4.0 HOLDER MOOD LAMP
CUP HOLDER MOOD LAMP
DRIVER CCS CUSHION WARMER
DRIVER DRIVER CCS SEAT CUSHION WARMER WARMER MODULE
DRIVER IMS SWITCH
DRIVER LEFT REAR IMS POWER SWITCH WINDOW SWITCH
DRIVER SEAT WARMER MODULE
ELECTRIC PARKING BRAKE SWITCH
FROM IPS 5 (DIAGRAM 4 OF 10)
FROM MULTI FUSE (DIAGRAM 1 OF 10)
FRONT SEAT WARMER, CCS SWITCH
GRN/BLK WIRE
I/P-A
I/P-C
I/P-D
I/P-F
INSTRUMENT CLUSTER
IPS 2
IPS 2 CTRL
IPS 6
IPS 6 CONTROL
IPS CONTROL IPS 6 CONTROL MODULE
IPS CONTROL MODULE
JOINT CONNECTOR UMA
LEFT AUDIO REMOTE CONTROL SWITCH
LEFT BLUETOOTH REMOTE CONTROL SWITCH
LEFT BLUETOOTH REMOTE CONTROL SWITCH (W/ NAVIGATION)
LEFT HEADLAMP
LEFT LEFT REAR LICENSE COMBINATION LAMP LAMP (OUT)
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR POWER WINDOW SWITCH
MANUAL A/C
NCA WIRE
ORG/ WIRE
PANORAMA SUNROOF
PANORAMA SUNROOF PASSENGER PASSENGER CCS SEAT CUSHION WARMER WARMER MODULE
PASSENGER CCS CUSHION WARMER
PASSENGER POWER WINDOW SWITCH
PASSENGER SEAT WARMER MODULE
PNK FROM MULTI FUSE (DIAGRAM 1 OF 10) WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RHEOSTAT
RIGHT BLUETOOTH REMOTE CONTROL SWITCH
RIGHT BLUETOOTH REMOTE CONTROL SWITCH (W/O NAVIGATION)
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT HEADLAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR POWER WINDOW SWITCH
RIGHT RIGHT REAR REAR COMBINATION COMBINATION LAMP LAMP (OUT) (IN)
RIGHT TRIP ECO REMOTE CONTROL SWITCH
RIGHT TRIP REMOTE CONTROL SWITCH
S/HEATER(FRT)/ SEAT VENT(FRT) FUSE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
STEERING WHEEL)
SUNROOF FUSE
SUPER VISION TYPE
TELLTALE LAMP
TO BRAKE SWITCH FUSE (DIAGRAM 6 OF 10)
W/ CCS
W/ NAVIGATION
W/ REAR SEAT WARMER W/O REAR SEAT WARMER
W/ UVO
W/ UVO W/O UVO
W/ W/O CCS CCS
W/O CCS
W/O NAVIGATION
W/O UVO
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit, except hybrid (5 of 10) -> CRASH FRONT PAD SEAT SWITCH WARMER, CCS SWITCH
