Kia Optima III facelift (2013-2015) computer high low data lines system Wiring diagram
This page shows the only wiring diagram for the component.computer high low data lines system, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer high low data lines system (1 of 1)
1 2 MEMORY PWR GND
BLK WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
COMPUTER HIGH LOW DATA LINES SYSTEM
E/R FUSE, RELAY BOX
EPS +
EPS IND
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
IND
INSTRUMENT CLUSTER
J/C UMC
MDPS FUSE
MDPS UNIT
MDPS UNIT (BASE OF STEERING COLUMN)
MEMORY PWR
MICOM
MULTI FUSE
PNK ON/START IN WIRE
PNK WIRE
RED WIRE
SMART JUNCTION BOX
SMART JUNCTION BOX (ABOVE LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> COMPUTER HIGH LOW DATA LINES SYSTEM
