Kia Optima III facelift (2013-2015) 8 15 16 on input on/start input memory pwr Wiring diagram
This page shows the only wiring diagram for the component.8 15 16 on input on/start input memory pwr, which is found in the car Kia Optima III facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 8 15 16 on input on/start input memory pwr (1 of 1)
40 2 SENSOR GROUND
8 15 16 ON INPUT ON/START INPUT MEMORY PWR
A/C CONTROL MODULE
A/CON FUSE
ACC/ON INPUT
AIR CONDITIONING SYSTEM
AUTO DEFOGGER ACTUATOR (RIGHT SIDE OF HVAC UNIT)
AUTO DEFOGGER SENSOR (TOP CENTER OF WINDSHIELD)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SWITCH
EXCEPT HYBRID HYBRID
FUSE
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON
HOT IN ON OR START
I/P-E
I/P-F
IND
JOINT CONNECTOR UMC
LEAK CURRENT AUTOCUT DEVICE
MEMORY
MODULE 1 FUSE
MODULE 4 FUSE
OFF
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
SMART JUNCTION BOX (ABOVE
YEL WIRE
Go to component -> Defoggers circuit, with auto defogger (1 of 2) -> 8 15 16 ON INPUT ON/START INPUT MEMORY PWR
