Tire pressure monitoring circuit, except hybrid for Kia Optima III (2010-2013)
Tire pressure monitoring circuit, except hybrid
BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER TPMS TREAD MICOM IND
COMPUTER DATA LINES SYSTEM
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX
I/P-G
INSTRUMENT CLUSTER
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MEMORY POWER
MODULE 1 FUSE
MODULE 4 FUSE
ON/START INPUT
POWER ROOM LP FUSE CONNECTOR
RED WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
TIRE PRESSURE MONITORING MODULE (BEHIND RIGHT SIDE OF DASH)
WHT WIRE
YEL WIRE
